Slewing angle limitation
Slewing limitation kit by proximity switches | Winch
500 kg high speed winch, with 25 m cable
(for H cranes only)
Stop end installed for CE versions |
|
|
 |  |
Cable remote control
3 or 4 functions proportional cable remote
control with 8 m cable (installed)
| Radio remote control
3 or 4 functions proportional radio remote
control – European frequency 434 Mhz (installed) |
|
|
 |  |
Additional function
Additional function on control valve bank (not activated) | Counter flange
|
| | |
 |  |
Crane base H
Sliding crane base with 1 hydraulic extendable stabiliser
(possibility to add second stabiliser, hydraulic or mechanical) | Crane base M
Sliding crane base with 1 mechanical extendable
stabiliser (possibility to add second stabiliser)
|
|
|
 |  |
Main Beam H
Additional beam with 1 hydraulic extendable stabiliser
(possibility to add second stabilizer hydraulic or mechanical) | Main beam M
Additional beam with 1 mechanical extendable stabiliser
(possibility to add second stabiliser)
|
 |  |
Tilting stabilisers
Hydraulic tilting stabilisers
| Mechanical stabiliser
|
| |
 |  |
Tilting kit
Tilting conversion kit for mechanical stabiliser | Side handle leg
Mechanical stabiliser leg with side handle |
|
|
 |  |
Manual extensions
Manual extensions “B” and “C”
| Fixed installation
Electric power pack 220/380 V (triphase motor)
2,2 KW with 8 lt. capacity tank
(only for H version cranes) Electric power pack 220 V
(single phase motor) 1,8 KW with 8 lt. capacity tank
(only for H version cranes) |
| |
| | Conversion and upgrade
Conversion kit from hydraulic version H
to electric version E 12/ 24V
Conversion kit from 1 to 2 hydraulic extensions
Conversion kit from 2 to 3 hydraulic extensions |
