ML 510 - 5 tm

ML 510 - 5 tm

Standard outreach: from 3.64 to 6.83 m
330° ball bearing slewing rotation
4 functions valve bank (one free)

Including
• 30 lt. oil tank
• Tie bolts set, nuts and lock nuts
• Spare grease cartridge for slewing worm gear

Options
• Supplementary stabilizer with hydraulic cylinders
• 3 – 4 functions proportional remote control (by cable or radio)
• 990 kg hydraulic winch – New system with
less cumbersome snatch block and quick disconnecting stop end system

OPTIONALS              APPLICATIONS
Slewing angle limitation
Slewing limitation kit by proximity switches
Winch
990 kg high speed winch, with 30 m cable
(for H cranes only)
Stop end installed for CE versions
Cable remote control
3 or 4 functions proportional cable
remote control with 8 m cable (installed)
Radio remote control
3 or 4 functions proportional radio remote control
– European frequency 434 Mhz (installed)
Additional function
Additional function on control valve bank (not activated)
Manual extensions
Manual extensions “B” “C” for ML 510 – ML 510 L

Manual extensions “D” for ML 510



Activations
One activated function with hose guide to boom
end, and 1 extra function on control valve bank



Two activated functions with hose guide to
boom end, and 2 extra functions on control valve bank
